            隨筆-341  評論-2670  文章-0  trackbacks-0
                明天得開始研究別人是怎么處理材質的了。目前使用的方法是(反射來源×反射基準)×折射比率+(光源×材質顏色)×(1-折射比率)+[(折射來源+底面反射)×衰減+(1-衰減)]×透明物體內部顏色


                等材質完全做完之后,目前的渲染算法就可以為GI服務了。

                最后是計算混合的代碼:
              1 VBool VL_RayRenderer::GetSample(IVL_RayGeometry::UnmanagedList& Objects , VRayPoint Position , VRayVector Direction , IVL_RayGeometry*& Geometry , VL_RayObjectSample& Sample)
              2 {
              3     VBool Available=false;
              4     for(VInt i=0;i<Objects.GetCount();i++)
              5     {
              6         VL_RayObjectSample TempSample;
              7         if(Objects[i]->GetNearestSample(Position,Direction,true,TempSample))
              8         {
              9             if(!Available)
             10             {
             11                 Geometry=Objects[i];
             12                 Sample=TempSample;
             13                 Available=true;
             14             }
             15             else if(TempSample.DirectionScale<=Sample.DirectionScale)
             16             {
             17                 Geometry=Objects[i];
             18                 Sample=TempSample;
             19             }
             20         }
             21     }
             22     return Available;
             23 }
             24
             25 VRayColor VL_RayRenderer::GetRefractionColor(IVL_RayGeometry::UnmanagedList& Objects , IVL_RayGeometry* Object , VRayPoint Position , VRayVector Direction , VInt ReflectionCounter)
             26 {
             27     VL_RayObjectSample Sample;
             28     if(Object->GetNearestSample(Position,Direction,false,Sample))
             29     {
             30         VDouble RefractionLength=(Sample.Position-Position).Length();
             31         VDouble InternalRatio=1-pow(Sample.RefractionIndex,-RefractionLength);
             32         VDouble OutRatio=0;
             33         VRayColor OutColor(0,0,0);
             34         VRayColor ReflectionColor(0,0,0);
             35         /*折射*/
             36         {
             37             VDouble SinB,CosB;
             38             VRayVector OutDirection=(-Sample.Normal).Refract(Sample.RefractionSinRatio,Direction,SinB,CosB);
             39             OutRatio=pow(CosB,Sample.RefractionRefindex);
             40             if(OutRatio>=Zero)
             41             {
             42                 VRayVector OutPosition=Sample.Position+OutDirection.Normalize().Scale(ReflectionOffsetScale);
             43                 OutColor=GetSampleColor(Objects,OutPosition,OutDirection,ReflectionCounter);
             44             }
             45         }
             46         /*反射*/
             47         {
             48             VBool ReflectionEnabled=Sample.ReflectionEnabled && ReflectionCounter>0 && !(1-OutRatio>=Zero);
             49             if(ReflectionEnabled)
             50             {
             51                 VRayVector ReflectionDirection=Sample.Normal.Reflect(Direction);
             52                 VRayVector ReflectionPosition=Sample.Position+ReflectionDirection.Normalize().Scale(ReflectionOffsetScale);
             53                 ReflectionColor=GetRefractionColor(Objects,Object,ReflectionPosition,ReflectionDirection,ReflectionCounter-1);
             54             }
             55         }
             56         /*混合*/
             57         OutColor=(OutColor.Scale(1-Sample.RefractionFaceRatio)+Sample.Color.Scale(Sample.RefractionFaceRatio));
             58         VRayColor MixColor=OutColor.Scale(OutRatio)+ReflectionColor.Scale(1-OutRatio);
             59         /*衰減*/
             60         return Sample.RefractionInternal.Scale(InternalRatio)+(MixColor*Sample.RefractionInternal).Scale(1-InternalRatio);
             61     }
             62     else
             63     {
             64         return VRayColor(0,0,0);
             65     }
             66 }
             67
             68 VRayColor VL_RayRenderer::GetSampleColor(IVL_RayGeometry::UnmanagedList& Objects , VRayPoint Position , VRayVector Direction , VInt ReflectionCounter)
             69 {
             70     IVL_RayGeometry* Geometry=0;
             71     VL_RayObjectSample Sample;
             72     if(GetSample(Objects,Position,Direction,Geometry,Sample))
             73     {
             74         VRayColor Light(0,0,0);
             75         VRayColor Reflection(0,0,0);
             76         VRayColor Refraction(0,0,0);
             77         /*光源*/
             78         for(VInt i=0;i<Lights.GetCount();i++)
             79         {
             80             VRayColor LightColor=Lights[i]->GetLight(Sample.Position);
             81             VRayVector LightDirection=Lights[i]->GetDirection(Sample.Position).Normalize();
             82             if(LightDirection.Length()<Zero)
             83             {
             84                 Light+=LightColor;
             85             }
             86             else
             87             {
             88                 VBool Skip=false;
             89                 VL_RayObjectSample LookBackSample;
             90                 if(GetSample(Objects,Sample.Position-LightDirection.Normalize().Scale(ReflectionOffsetScale),-LightDirection,Geometry,LookBackSample))
             91                 {
             92                     VRayColor LookBackColor=Lights[i]->GetLight(LookBackSample.Position);
             93                     if(LookBackColor.R+LookBackColor.G+LookBackColor.B>Zero)
             94                     {
             95                         Skip=true;
             96                     }
             97                 }
             98                 if(!Skip)
             99                 {
            100                     VDouble Scale=Sample.Normal.Normalize()*(-LightDirection);
            101                     if(Scale>0)
            102                     {
            103                         Light+=LightColor.Scale(Scale);
            104                     }
            105                 }
            106             }
            107         }
            108         /*反射*/
            109         if(ReflectionCounter>0 && Sample.ReflectionEnabled)
            110         {
            111             VRayVector ReflectedDirection=Sample.Normal.Reflect(Direction.Scale(-Sample.DirectionScale));
            112             VRayVector ReflectedPosition=Sample.Position+ReflectedDirection.Normalize().Scale(ReflectionOffsetScale);
            113             Reflection=GetSampleColor(Objects,ReflectedPosition,ReflectedDirection,ReflectionCounter-1);
            114         }
            115         /*折射*/
            116         if(Sample.RefractionEnabled)
            117         {
            118             VRayVector RefractionDirection=Sample.Normal.Refract(1/Sample.RefractionSinRatio,Direction);
            119             if(RefractionDirection.Length()>Zero)
            120             {
            121                 VRayPoint RefractionPosition=Sample.Position+RefractionDirection.Normalize().Scale(ReflectionOffsetScale);
            122                 Refraction=GetRefractionColor(Objects,Geometry,RefractionPosition,RefractionDirection,ReflectionCounter);
            123                 Refraction=Sample.Color.Scale(Sample.RefractionFaceRatio)+Refraction.Scale(1-Sample.RefractionFaceRatio);
            124             }
            125         }
            126         /*混合*/
            127         return
            128             (Light*Sample.Color).Scale(1-Sample.ReflectionRatio)+
            129             (Reflection*Sample.ReflectionBase).Scale(Sample.ReflectionRatio)+
            130             Refraction;
            131     }
            132     else
            133     {
            134         return VRayColor(0,0,0);
            135     }
            136 }
            137
            138 void VL_RayRenderer::Render(IVL_RayGeometry::UnmanagedList& Objects , IVL_RayRenderingInformation* Information)
            139 {
            140     VL_WinBitmap::Ptr Buffer=new VL_WinBitmap(Information->GetBufferWidth(),Information->GetBufferHeight(),VL_WinBitmap::vbb24Bits,true);
            141     VInt BufferWidth=Buffer->GetWidth();
            142     VInt BufferHeight=Buffer->GetHeight();
            143     for(VInt Y=0;Y<BufferHeight;Y++)
            144     {
            145         VByte* ScanLine=Buffer->GetScanLines()[Y];
            146         for(VInt X=0;X<BufferWidth;X++)
            147         {
            148             VByte* Pixel=&ScanLine[X*3];
            149             VDouble XRatio=(VDouble)(X*2-BufferWidth)/BufferWidth;
            150             VDouble YRatio=(VDouble)(Y*2-BufferHeight)/BufferHeight;
            151             VRayVector RenderingDirection=(FScreenCenter-FPosition)+FScreenRightVector.Scale(XRatio)+FScreenDownVector.Scale(YRatio);
            152             VRayColor RenderingColor=GetSampleColor(Objects,FPosition,RenderingDirection,MaxReflectionLevelCount);
            153             Pixel[0]=RangeColorChannel(RenderingColor.B);
            154             Pixel[1]=RangeColorChannel(RenderingColor.G);
            155             Pixel[2]=RangeColorChannel(RenderingColor.R);
            156         }
            157         Information->OnRendering(Buffer,Y+1);
            158     }
            159     Information->OnFinished(Buffer);
            160 }
            posted on 2009-01-22 06:02 陳梓瀚(vczh) 閱讀(2219) 評論(2)  編輯 收藏 引用 所屬分類: 3D

            評論:
            # re: 實現透明物體折射 2009-01-22 18:19 | abettor
            太帥了!  回復  更多評論

            # re: 實現透明物體折射 2009-04-15 07:25 | 小螞蟻
            GI是什么東西,你自己的寫的圖形引擎?  回復  更多評論
