Antenna Placement
| Time Limit: 1000MS |
|
Memory Limit: 65536K |
| Total Submissions: 4127 |
|
Accepted: 2032 |
Description
The Global Aerial Research Centre has been allotted the task of building the fifth generation of mobile phone nets in Sweden. The most striking reason why they got the job, is their discovery of a new, highly noise resistant, antenna. It is called 4DAir, and comes in four types. Each type can only transmit and receive signals in a direction aligned with a (slightly skewed) latitudinal and longitudinal grid, because of the interacting electromagnetic field of the earth. The four types correspond to antennas operating in the directions north, west, south, and east, respectively. Below is an example picture of places of interest, depicted by twelve small rings, and nine 4DAir antennas depicted by ellipses covering them.
Obviously, it is desirable to use as few antennas as possible, but still provide coverage for each place of interest. We model the problem as follows: Let A be a rectangular matrix describing the surface of Sweden, where an entry of A either is a point of interest, which must be covered by at least one antenna, or empty space. Antennas can only be positioned at an entry in A. When an antenna is placed at row r and column c, this entry is considered covered, but also one of the neighbouring entries (c+1,r),(c,r+1),(c-1,r), or (c,r-1), is covered depending on the type chosen for this particular antenna. What is the least number of antennas for which there exists a placement in A such that all points of interest are covered?
Input
On the first row of input is a single positive integer n, specifying the number of scenarios that follow. Each scenario begins with a row containing two positive integers h and w, with 1 <= h <= 40 and 0 < w <= 10. Thereafter is a matrix presented, describing the points of interest in Sweden in the form of h lines, each containing w characters from the set ['*','o']. A '*'-character symbolises a point of interest, whereas a 'o'-character represents open space.
Output
For each scenario, output the minimum number of antennas necessary to cover all '*'-entries in the scenario's matrix, on a row of its own.
Sample Input
2
7 9
ooo**oooo
**oo*ooo*
o*oo**o**
ooooooooo
*******oo
o*o*oo*oo
*******oo
10 1
*
*
*
o
*
*
*
*
*
*
Sample Output
17
5
思路：二分圖匹配，最小路徑覆蓋，建圖是按自己的感覺建的相鄰的兩個連邊，（v,u），（u,v）都加到圖里面，然后最大匹配就是原先的兩倍（不明白）
再然后答案是總點數n-匹配數x
若最大匹配為X，已蓋點（指的是兩個一組被一個基站覆蓋）個數=2*x，未蓋點=sum（總點數）-已蓋點=sum-2*x應為未蓋點肯定是單的，
所以覆蓋未蓋點的基站個數肯定與未蓋點個數一樣=sum-s*x所以總的基站數為 x+sum-2*x=sum-x
代碼
1
#include<stdio.h>
2#include<string.h>
3#include<math.h>
4#define MAXSIZE 405
5
int dd[4][2]=
{{-1,0},{1,0},{0,1},{0,-1}};
6int result[MAXSIZE+1];
7short data[MAXSIZE+1][MAXSIZE+1],state[MAXSIZE+1];
8int h[45][20];
9int n,m,sum,ans;
10char map[45][20];
11void init()
12{
13
int i,j,k;
14 int xx,yy;
15 sum=0;
16 memset(result,0,sizeof(result));
17 memset(data,0,sizeof(data));
18 scanf("%d%d",&n,&m);
19 for (i=0; i<n ; i++ )
20
{
21 scanf("%s",&map[i]);
22 for (j=0; j<m ; j++ )
23 if (map[i][j]=='*')
24 {
25 sum++;
26 h[i][j]=sum;
27
}
28 }
29 for (i=0; i<n ; i++)
30 for (j=0; j<m; j++)
31 if (map[i][j]=='*')
32 {
33 for (k=0; k<=3; k++)
34 {
35 xx=i+dd[k][0];
36 yy=j+dd[k][1];
37 if (xx>=0&&yy>=0&&xx<n&&yy<m&&map[xx][yy]=='*')
38 data[h[i][j]][h[xx][yy]]=1;
39 }
40 }
41
}
42int find(int a)
43{
44 int i;
45 for (i=1; i<=sum ; i++ )
46 {
47 if (data[a][i]==1&&!state[i])
48 {
49 state[i]=1;
50 if (result[i]==0||find(result[i]))
51 {
52 result[i]=a;
53 return 1;
54 }
55 }
56 }
57 return 0;
58}
59int main()
60{
61 int t,i,j;
62 scanf("%d",&t);
63 for (i=1; i<=t ; i++ )
64 {
65 ans=0;
66 init();
67 for (j=1; j<=sum ; j++ )
68 {
69 memset(state,0,sizeof(state));
70 if (find(j)) ans++;
71 }
72 printf("%d\n",sum-ans/2);
73 }
74 return 0;
75}
